Description
With 12 output channels, this unit is ideal for controlling larger circuits of RGB, CT or single colour LED Strip. Includes DMX 5-Pin to 3-Pin Cable.
This decoder also has the option to assign multiple channels to one address. Dimming curve options include; standard, linear, LOG, custom 0.1-9.9 dimming curve.
The decoder requires a low voltage input. It receives a DMX control signal from a suitable controller in order to supply the correct dimming output across 12 channels. DMX connects via standard XLR-5, RJ45 plugs or screw terminals. The low voltage supply and lights connect via screw terminals on the side of the unit. A DMX signal amplifier is also built in to the unit.
The decoder operates on a low voltage 12~24V DC circuit, providing a PWM output, ideal for dimming LEDs.
Includes DMX 5-Pin to 3-Pin Cable
Specification
LT-12-OLED Decoder
-
Input signal – DMX512/RDM
-
Voltage 12V~24V DC
-
Output – Constant Voltage
-
Channels – 12
-
Current – 3A× 12CH Max 48A
-
Max output power – 576W/1152W(12V/24V)
